Frekventni regulator EKVR - 3.0kw 220v

Input and output

Input voltage range: 380 / 220V ± 15%

Input frequency range: 40 ~ 60Hz

Output voltage range: 0 ~ rated input voltage

Output frequency range: 0 ~ 600Hz ( 0-2000HZ for V1.15 software version)

Peripheral interface

Programmable digital input: 4-WAY input(8-Way for the digital port inputof F103 version )

Programmable analog quantity: FV: 0~10V input, FI: 0〜20mA input.

Open collector output: 1-WAYoutput

Relay output: 1-WAY output

AO(analog output) FO : 1-WAY output: 0〜10V output

Technical performance

Control mode:SVC, V/F control

Over-load ability: 150% of rated current 60s; 180% of rated current 10s

Starting torque: SVC: 0.5Hz / 150% (SVC)

Speed-regulating ratio: SVC: 1: 100

User Manual

Speed control precision: SVC: ± 0.5% maximum speed

Carrier frequency: 1.0K ~ 15.0KHZ

Functional characteristic

Frequency set mode:digital set, analog quantity set, serial communications set,

SPD, PID set

PID control function

SPD control function: eight-stage speed(16-stage speed for the F103 version)

Swing frequency control function

Non-stop function for momentary interruption

Restarting function of rotational speed tracking: realizing the non-impact of

smooth start-up of the motor in rotation

Automatic voltage regulation function: when the network voltage changes, it can

maintain the constant output voltage automatically

Providing multi-fault protection function: overcurrent, overvoltage, undervoltage,

overtemperature, phase loss, output short-circuit, overload, etc.

Operating environment

Operating ambient temperature :-15℃to + 50℃

Operating humidity: 90% RH or less (no condensation)

Altitude 1000 meters or less above sea level. Over 1000 meters, every 100 meters

decreases 3%; Over 2000 meters every 100 meters decreases 5%.

Other non-corrosive, flammable gases, no conductive dust
